Old 11-13-2012, 02:00 PM   #1 (permalink)
Senior Member

Rix65's Avatar

Join Date: Sep 2004
Location: Pacific Northwest
Posts: 200
Default Exhaust Clearance

Guys running four links in your 65-67, show me how you've tackled the interference problem. My panhard bar is leaving me little room to run the exhaust from the mufflers back out to the stock location. I'd rather not run it out the side if avoidable.

Thanks
__________________
65 Coupe restofied. T-5, 9-inch rear, Mass Flow EFI, 5.0 bored and stroked, Shelby drop, performance coils four wheel disk, Heidts adjustable 4-link.

http://www.cardomain.com/ride/737158/1965-ford-mustang
Rix65 is offline   Reply With Quote Quick reply to this message
Sponsored Links
Advertisement

Old 11-13-2012, 07:03 PM   #2 (permalink)
Senior Member

IMCOBRA's Avatar

Join Date: Aug 2012
Posts: 349
Default

That is exactly why I did not use the four link set up when doing my resto modded 70 fastback because I could not see any easy way to get the exhaust over the axle and out to the stock location. Maybe someone will chime in and show us how.
__________________
Forrest Robinson
Tucson AZ.
IMCOBRA is offline   Reply With Quote Quick reply to this message
Old 11-13-2012, 07:29 PM   #3 (permalink)
Member

Join Date: Sep 2012
Posts: 46
Default

Under the axle, side exit, or dump before the axle are probably going to be your only options.
Nick_R_23 is offline   Reply With Quote Quick reply to this message
Old 11-13-2012, 08:11 PM   #4 (permalink)
Senior Member

DrStang's Avatar

Join Date: Apr 2001
Location: Palm Springs, California
Posts: 1,946
Default

I dump right before the axle with turn downs. No issues with exhaust smell etc...

I've seen fellas run it under the rear axle housing with success.
__________________
http://i1370.photobucket.com/albums/...psb3575849.jpg
"A good friend will help you move. A great friend will help you move a dead body"

1965 A-Code Fastback
Built, September 14, 1964 (San Jose)
Viper red, White/red interior
TCP R&P, G Bar rear 4 link/w shockwaves
Global West Upper/Lower/Strut Rods
Ride-Tech Air ride
4 wheel Cobra disc brakes/Hydroboost
363 Stroker/Paxton Supercharger
Mass-Flo EFI
Owned since 1983
DrStang is offline   Reply With Quote Quick reply to this message
Old 11-13-2012, 08:33 PM   #5 (permalink)
Supporting Member
Myopic

dodgestang's Avatar

Join Date: Aug 2002
Location: Omnipresent
Posts: 16,211
Default

Turn downs....it makes it louder too....some people think of that as a feature....not me personally....but some do.

__________________
Nick
1965 Fastback 410c AOD - DT
1967 Fastback 347 FMX - Cruiser
1968 Fastback 351w T5 - Brute
1996 Dodge Viper GTS

https://www.youtube.com/watch?v=0LUK2D0GjdY

Last edited by dodgestang; 11-13-2012 at 08:35 PM.
dodgestang is offline   Reply With Quote Quick reply to this message
Old 11-14-2012, 11:56 AM   #6 (permalink)
Senior Member

Campindog's Avatar

Join Date: Oct 2010
Location: Campbell, Ca
Posts: 234
Default

Here's my 2.5" exhaust with a torque arm and a panhard bar. It should be the same with a parallel 4 link. Triangulated 4 link might be tougher, but then you probably wouldn't use a panhard bar due to binding.
Attached Images
File Type: jpg Mustang suspension 023.jpg (38.2 KB, 103 views)
__________________
68 convertible
DD, mild 331, T5, torque arm
Campindog is offline   Reply With Quote Quick reply to this message
Old 11-15-2012, 12:36 AM   #7 (permalink)
Senior Member

Rix65's Avatar

Join Date: Sep 2004
Location: Pacific Northwest
Posts: 200
Default

Campindog,
Hows the clearance near your brake lines etc. with this setup?
__________________
65 Coupe restofied. T-5, 9-inch rear, Mass Flow EFI, 5.0 bored and stroked, Shelby drop, performance coils four wheel disk, Heidts adjustable 4-link.

http://www.cardomain.com/ride/737158/1965-ford-mustang
Rix65 is offline   Reply With Quote Quick reply to this message
Old 11-15-2012, 12:38 AM   #8 (permalink)
Senior Member

Rix65's Avatar

Join Date: Sep 2004
Location: Pacific Northwest
Posts: 200
Default

Dr.Stang,
Do you have a rear shot of your car? I'm concerned about droan coming into the cab using turn downs.
__________________
65 Coupe restofied. T-5, 9-inch rear, Mass Flow EFI, 5.0 bored and stroked, Shelby drop, performance coils four wheel disk, Heidts adjustable 4-link.

http://www.cardomain.com/ride/737158/1965-ford-mustang
Rix65 is offline   Reply With Quote Quick reply to this message
Old 11-15-2012, 10:58 AM   #9 (permalink)
Senior Member

Campindog's Avatar

Join Date: Oct 2010
Location: Campbell, Ca
Posts: 234
Default

You can kind of see the brake line at the top of this picture. Plenty of room and no problems. As the suspension compresses, it moves away from the exhaust. I've been driving with it for ~3 years.
Attached Images
File Type: jpg 416.jpg (42.2 KB, 57 views)
__________________
68 convertible
DD, mild 331, T5, torque arm
Campindog is offline   Reply With Quote Quick reply to this message
Old 11-15-2012, 02:59 PM   #10 (permalink)
Senior Member

Rix65's Avatar

Join Date: Sep 2004
Location: Pacific Northwest
Posts: 200
Default

Campindog,

Thanks for your input. What are you hanging the tailpipes from? Near the valance?
__________________
65 Coupe restofied. T-5, 9-inch rear, Mass Flow EFI, 5.0 bored and stroked, Shelby drop, performance coils four wheel disk, Heidts adjustable 4-link.

http://www.cardomain.com/ride/737158/1965-ford-mustang
Rix65 is offline   Reply With Quote Quick reply to this message
Old 11-16-2012, 02:46 PM   #11 (permalink)
Senior Member

Campindog's Avatar

Join Date: Oct 2010
Location: Campbell, Ca
Posts: 234
Default

They turn down at the valance. Regular ol hangers attached to the frame with insulators. Plenty of room w/o leaf springs.
Attached Images
File Type: jpg 057.jpg (35.1 KB, 43 views)
__________________
68 convertible
DD, mild 331, T5, torque arm
Campindog is offline   Reply With Quote Quick reply to this message
Old 11-17-2012, 08:47 AM   #12 (permalink)
Junior Member

Join Date: Nov 2012
Posts: 1
Default

thanks for all the information guys
blesak is offline   Reply With Quote Quick reply to this message
Old 11-21-2012, 12:04 AM   #13 (permalink)
Senior Member

DrStang's Avatar

Join Date: Apr 2001
Location: Palm Springs, California
Posts: 1,946
Default

Here's my under car.

__________________
http://i1370.photobucket.com/albums/...psb3575849.jpg
"A good friend will help you move. A great friend will help you move a dead body"

1965 A-Code Fastback
Built, September 14, 1964 (San Jose)
Viper red, White/red interior
TCP R&P, G Bar rear 4 link/w shockwaves
Global West Upper/Lower/Strut Rods
Ride-Tech Air ride
4 wheel Cobra disc brakes/Hydroboost
363 Stroker/Paxton Supercharger
Mass-Flo EFI
Owned since 1983
DrStang is offline   Reply With Quote Quick reply to this message
Old 11-22-2012, 10:28 AM   #14 (permalink)
Senior Member

Campindog's Avatar

Join Date: Oct 2010
Location: Campbell, Ca
Posts: 234
Default

DrStang, The Ridetech stuff looks bullet-proof! Nice ride.
__________________
68 convertible
DD, mild 331, T5, torque arm
Campindog is offline   Reply With Quote Quick reply to this message
